2117 Aluminum Square Rod



1. Execution Standard:

2117 aluminum alloy complies with the ASTM standard B211, which specifies the requirements for chemical composition, physical properties, and mechanical properties of aluminum and aluminum alloys.



2. Specific Chemical Composition Range:

- Aluminum (Al) content: 87.0% - 91.4%

- Copper (Cu) content: 2.0% - 2.8%

- Manganese (Mn) content: 0.5% - 1.5%

- Silicon (Si) content: less than 0.2%

- Iron (Fe) content: less than 0.7%

- Zinc (Zn) content: 2.0% - 2.8%

- Chromium (Cr) content: less than 0.10%

- Other element content: less than 0.15%



3. Mechanical Properties:

- Tensile Strength: 390 MPa - 510 MPa

- Yield Strength: 310 MPa - 420 MPa

- Elongation at Break: 10% - 14%



4. Applications:

2117 aluminum alloy is widely used in aerospace, automotive, railway, and other industries, especially in environments requiring high strength and corrosion resistance. 2117 aluminum alloy is commonly used to manufacture various aerospace structural components, vehicle structural parts, wheels, hydraulic pipes, and fittings.



5. Different Conditions:

The most common conditions for 2117 aluminum alloy are T3, T4, T6, etc.



6. Advantages:

- High strength and corrosion resistance

- Good weldability and machinability



7. Disadvantages:

- Average plasticity and toughness



8. Most Common Forms:

The most common forms of 2117 aluminum alloy are rods, sheets, profiles, and pipes.



9. International Grade Comparisons:

- United States Grade: AA2117/T3

- Japanese Grade: A2117/T3

- Chinese Grade: 2117



In conclusion, 2117 aluminum alloy complies with the ASTM standard B211 and has a specific chemical composition including aluminum, copper, manganese, silicon, iron, zinc, chromium, and other elements. The most common conditions are T3, T4, T6, etc. It is widely used in aerospace, automotive, railway, and other industries, with advantages of high strength, corrosion resistance, good weldability, and machinability. The most common forms include rods, sheets, profiles, and pipes. In different countries, it is referred to by different grade names, such as AA2117/T3 in the United States, A2117/T3 in Japan, and 2117 in China.





Article	Aluminium ·
Standard	AISI 、ASTM 、EN 、BS 、GB 、DIN 、JIS
Material	1060、1065、1070、1070A 、1080、, 1080A 、,1085、1100、1200、1230、1450、1260、1370、1275、1185、1285、1385、2004、2011、2014、 2017、2014A 、2017A 、2214、2117、2218、2618、2618A 、2219、2519、2024、2524、3002、3102、3103、1235、1435、3003、3103、,3103A 、 3203、3004、3004A 、 3005, 3006 , 3007 、3107、1050、1060、2014、2024、3003、5052、5083、6082、7075、5005、5052、5083、6061、 6063,7075,6082,7075,7050,7A04,7A09,8011,8082, etc
Size	Aluminum rod: φ 10mm- φ410mm Aluminum plate: 0.5mm-600mm Aluminum square bar: 8mmx8mm-570mmx10mm Angle aluminum: 8mmx8mmx1mm-280mmx40mmx4mm Aluminum roll: 0.3-3mm or as required
State	HO,H12,H14,H16,H18,H19,H22,H24,H26,H28,F,H112,H111 T651,T3,T451,T4,T6,
Output to	Singapore, Indonesia, South Korea, Thailand, Vietnam, Saudi Arabia, Brazil, Spain, Canada, the United States, and Egypt, India, Kuwait, Dubai, Kuwait, Peru, Mexico, and Russia, Malaysia, etc.
Pack	Bundle packaging, export standard packaging or according to customer requirements
Delivery time	7-15 days or according to the order quantity or negotiation
Price clause	Price terms CIF, FOB, CFR.
Pay	Letters of credit, wire transfer, etc
Minimum order	One ton
