S550GD+Z Steel Plate
S550GD+Z is a high-strength hot-dip galvanized steel sheet with the execution standard of EN 10346:2015. It is primarily used in the manufacturing of structural components, automotive parts, and containers that require high strength and excellent corrosion resistance. The chemical composition range of S550GD+Z includes carbon (C) ≤ 0.20%, silicon (Si) ≤ 0.6%, manganese (Mn) ≤ 2.2%, phosphorus (P) ≤ 0.035%, sulfur (S) ≤ 0.03%, and so on.
Description
Product Application
S550GD+Z is a high-strength hot-dip galvanized steel sheet with the execution standard of EN 10346:2015. It is primarily used in the manufacturing of structural components, automotive parts, and containers that require high strength and excellent corrosion resistance. The chemical composition range of S550GD+Z includes carbon (C) ≤ 0.20%, silicon (Si) ≤ 0.6%, manganese (Mn) ≤ 2.2%, phosphorus (P) ≤ 0.035%, sulfur (S) ≤ 0.03%, and so on.
The tensile strength of S550GD+Z ranges from 550 to 700 megapascals (MPa), with a yield strength above 550 MPa and a fracture elongation of over 16%. These properties make it a steel material with high strength and excellent reliability.
S550GD+Z exhibits good weldability, formability, and corrosion resistance. Its surface coating is uniform and dense, providing superior corrosion protection and suitable for working in harsh environments, extending equipment lifespan.
The main disadvantage of S550GD+Z is that it has a higher cost, resulting in relatively higher manufacturing costs. Additionally, special attention should be paid during processing to avoid surface scratches or blemishes.
S550GD+Z is commonly available in hot-rolled coils and cold-rolled coils, allowing for different forms to be selected based on specific application requirements.
In terms of international comparison, similar grades to S550GD+Z include HSLAS-F Gr 80 (American standard) and S550GD+ZF (European standard). Different countries have different steel standards and specifications, so it is necessary to compare and analyze various standards and specifications when selecting the appropriate grade.
In conclusion, S550GD+Z is a hot-dip galvanized steel sheet with high strength and excellent corrosion resistance, widely used in the manufacturing of structural components, automotive parts, and containers. However, it has the disadvantage of higher cost, and extra care is required during processing to avoid surface scratches or blemishes. Therefore, when selecting S550GD+Z, various factors need to be considered.
Product Parameter:
|
Article |
Galvanized plate roll |
|
Standard |
AISI 、ASTM 、EN 、BS 、GB 、DIN 、JIS |
|
Material |
DX51D ，1.0917，DX52D ，1.0918，DX53D ，1.0951，DX54D ，1.0952，DX55D ，1.0962 ，DX56D ，DX57D 1.0963 S220GD ，1.0241，S250GD ，1.0242，S280GD ，1.0244，S320GD ，1.025 ，S350GD ，S390GD ，1.0529 S420GD 1.0239，S550GD ，1.0531，HX160YD ，1.091，HX180YD ，1.0921，HX180BD ，1.0914 HX220YD ，1.0923，HX220BD ，1.0919 ，HX260YD ，1.0926 ，HX260BD ，1.0924，HX260LAD ， HX300YD ，1.0929 HX300BD ，1.093，HX300LAD ，1.0932，HX340BD ，HX340LAD ，1.0945， HX380LAD ，HX420LAD，1.0934, HX460LAD, 1.099, HX500LAD, 1.0991, etc |
|
Paint-coat |
+Z +ZF +ZA +AZ +AS +ZM |
|
Output to |
Singapore, Indonesia, South Korea, Thailand, Vietnam, Saudi Arabia, Brazil, Spain, Canada, the United States, and |
|
Pack |
Bundle packaging, export standard packaging or according to customer requirements |
|
Delivery time |
7-15 days or according to the order quantity or negotiation |
|
Price clause |
Price terms CIF, FOB, CFR. |
|
Pay |
Letter of credit, wire transfer, etc |
|
Minimum order |
One ton |
Why choose us?
- Our products are eco-friendly and sustainable, making them an excellent choice for environmentally conscious consumers.
- We stick to the business philosophy of 'product quality as life, service for development'.
- We work closely with our customers to understand their needs and provide customized solutions.
- Our continuous innovation and unparalleled performance of S550GD has made us a brand to be reckoned with.
- Our Galvanized Steel Coil/sheet products are easy to install and require minimal maintenance.
- We constantly strengthen the construction of corporate culture, improve the sense of social responsibility of employees and carefully cast the industry brand.
- Our Galvanized Steel Coil/sheet products are highly resistant to corrosion and are ideal for a variety of applications.
- Protecting the environment and benefiting the society is our responsibility that we always adhere to.
- As a supplier and manufacturer, we offer competitive prices for our products.
- We have professional people to design the appearance and structure of our S550GD, so that it is always in the leading position of similar products.
