Low Alloy High Strength Steel Sheets: Q390 and Q460

1. Overview

Q390 and Q460 are low alloy high strength structural steels specified by the Chinese standard GB/T 1591-2018. They contain small amounts of alloying elements (e.g., manganese, silicon, niobium, vanadium) to achieve higher strength and better comprehensive properties than ordinary carbon steel, while maintaining good weldability and formability.

2. Grades and Mechanical Properties

Grade	Yield Strength \(R_eL\) (MPa) (Thickness ≤ 16mm)	Tensile Strength \(R_m\) (MPa)	Elongation A (%)	Impact Test (Temperature, Energy)
Q390	≥390	490–650	≥17	+20℃, ≥34J (Charpy V-notch)
Q460	≥460	550–720	≥17	+20℃, ≥34J (Charpy V-notch)



Key Notes:

Higher grades (e.g., Q460) offer significantly greater load-bearing capacity than lower grades (e.g., Q345).

For thicker plates (>16mm), yield strength decreases slightly (e.g., Q460 with thickness 16–100mm has \(R_eL\) ≥420 MPa).

3. Chemical Composition (Typical Values, %)

Grade	C	Si	Mn	P	S	Nb	V	Ti	Alt
Q390	≤0.20	0.20–0.55	1.00–1.60	≤0.035	≤0.035	0.015–0.060	0.015–0.060	0.02–0.20	≥0.015
Q460	≤0.18	0.20–0.60	1.00–1.70	≤0.030	≤0.030	0.020–0.070	0.020–0.080	0.02–0.20	≥0.015



Alloying Elements Role:

Niobium (Nb), Vanadium (V), Titanium (Ti): Refine grain structure, improve strength and toughness.

Manganese (Mn): Enhances hardenability and strength.

Aluminum (Alt): Acts as a deoxidizer and stabilizes grain size.
