LR DH42 Steel Plate





Pre - welding Preparation

Surface Cleaning: Before welding LR DH42 steel plates, it's crucial to clean the surfaces to be welded. Remove any dirt, grease, rust, and scale using mechanical methods such as grinding or wire - brushing, or chemical methods. For example, using a solvent - based cleaner can effectively remove grease. This is because contaminants on the surface can lead to poor weld quality, such as porosity or lack of fusion.



Plate Alignment: Ensure accurate alignment of the steel plates. Use appropriate jigs or fixtures to hold the plates in position during welding. The gap between the plates should be maintained within the recommended range. For example, a root gap of around 2 - 4 mm is often suitable for most welding processes used with LR DH42 steel plates.



Pre - heating: Depending on the thickness of the steel plates and the welding conditions, pre - heating may be necessary. For thick - section LR DH42 steel plates (usually above 20 - 25 mm), pre - heating to a temperature range of 100 - 150°C can reduce the risk of cold cracking. Pre - heating helps to slow down the cooling rate of the weld and the heat - affected zone (HAZ), preventing the formation of hard and brittle microstructures.















High Strength Chemical Composition
Grade	C	Si	Mn	P	S
LR DH42	0.18	0.10-0.35	0.9-1.6	0.035	0.035







Welding Process Selection

Shielded Metal Arc Welding (SMAW): This is a commonly used welding method for LR DH42 steel plates. When using SMAW, select electrodes that are suitable for the steel grade. For example, electrodes with a low - hydrogen coating are preferred as they can reduce the risk of hydrogen - induced cracking. The welding current and voltage should be adjusted according to the electrode diameter and the thickness of the plates. For a 3.2 - mm - diameter electrode, a welding current of around 90 - 130 A and a voltage of around 20 - 25 V are typical settings.
