X2NiCrAlTi3220

Chemical composition
C max 0.03
Si max 0.7
Mn max 1
Ni 32 - 35
P max 0.02
S max 0.015
Cr 20 - 23
Ti max 0.6
Al 0.15 - 0.45

mechanical property

Rm - Tensile strength (MPa) (+AT) 450-700
Rp0.2 0.2% proof strength (MPa) (+AT) 180

KV - Impact energy (J) longitud., (+AT) +20°120
KV - Impact energy (J) transverse, (+AT) +20°90 -196° 60

A - Min. elongation at fracture (%) transverse, (+AT) 30
A - Min. elongation at fracture (%) longitud., (+AT) 35

In terms of mechanical properties, X2NiCrAlTi3220 exhibits good strength and ductility. It has the ability to endure significant mechanical stresses without fracturing easily. This makes it suitable for applications where both load-bearing capacity and resistance to deformation are required. For example, in the manufacturing of structural components in high-temperature machinery or in the aerospace industry, where parts need to withstand extreme conditions during flight and operation.

The alloy also shows good creep resistance. Creep is the slow and continuous deformation of a material under a constant load and high temperature. X2NiCrAlTi3220's resistance to creep ensures that the dimensions and shape of the components remain stable over long periods of time, which is vital for the proper functioning and safety of equipment.

Furthermore, X2NiCrAlTi3220 has favorable thermal conductivity. This property allows for efficient heat transfer within the alloy, which is beneficial in applications where heat dissipation or absorption is crucial. It can help in optimizing the thermal performance of systems and reducing the risk of overheating.

Regarding its fabricability, it can be processed through various methods, including casting, forging, and machining. However, due to its specific properties, specialized techniques and careful control of processing parameters are often necessary to obtain the desired quality and performance. Overall, X2NiCrAlTi3220 is a valuable alloy that offers a comprehensive set of properties, making it an ideal choice for many high-temperature and demanding applications in industries such as energy, aerospace, and manufacturing.
