1.7103 Steel
Products Description 1.7103 Steel 1.7103 steel is a remarkable material with a wide range of applications and outstanding properties. This type of steel is known for its exceptional strength and durability, making it a popular choice in various industries. One of the key characteristics of...
Description
Products Description
WS 1.7103 (AISI 9254)is a Spring Steel which is manufactured in Rod, Bar and coil.
| Chemical Composition Limits | |||||||
| Weight % | C | Cr | Mn | Si | S | P | Fe |
| 67 SiCr5 | 0.67 | 0.60-0.80 | 0.40-0.60 | 0.90-1.10 | 0.010-0.035 | 0.035 max | Rem |
| WS 1.7103 | 0.67 | 0.60-0.80 | 0.40-0.60 | 0.90-1.10 | 0.010-0.035 | 0.035 max | Rem |
| AISI 9254 | 0.67 | 0.60-0.80 | 0.40-0.60 | 0.90-1.10 | 0.010-0.035 | 0.035 max | Rem |
67SiCr5 is available in:
Precision cold drawn, Ground polished pointed and chamfered ends above 4mm Ø Eddy-current tested above 5mm Ø bars.
Delivery Form
For automatic lathes of 3m (2m) lengths
Tolerance
Standard ISO h8
Tensile Strength
At delivery about 740 N/mm2
Heat Treatment
Hardening Temperature (Oil): (830-860 ºC max)
Obtainable hardness: 61 HRC
After Tempering: 40-60 BRC
In conclusion, 1.7103 steel is a versatile and reliable material with exceptional strength, toughness, and corrosion resistance. Its wide range of applications and availability in different forms make it a valuable choice for engineers and manufacturers. Whether it's for structural support, mechanical components, or other demanding applications, 1.7103 steel can deliver the performance and durability needed.
