6150 Alloy Steel
Products Description 6150 Alloy Steel: A High-Performance Material for Diverse Applications 6150 alloy steel is a widely recognized and highly regarded material in the field of engineering and manufacturing. This alloy steel offers a unique combination of properties that make it suitable for a...
Description
Products Description
Chemical Composition
|
Standard |
Grade | C | Mn | P | S | Si | Cr | V |
| ASTM A29 | 6150 | 0.48-0.53 | 0.70-0.90 | 0.035 | 0.040 | 0.15-0.35 | 0.80-1.10 |
≥0.15 |
|
EN 10083 |
1.8159 /51CrV4 |
0.47-0.55 | 0.70-1.10 | 0.025 | 0.025 | ≦0.40 | 0.90-1.20 | 0.10-0.25 |
| JIS G4801 | SUP 10 | 0.47-0.55 | 0.65-0.95 | 0.030 | 0.030 | 0.15-0.35 | 0.80-1.10 |
0.15-0.25 |
|
GB/T 3077 |
50CrVA | 0.47-0.54 | 0.50-0.80 | 0.030 | 0.030 |
0.17-0.37 |
0.80-1.10 | 0.10-0.20 |
Mechanical Properties
|
Properties |
Conditions | ||
|
T (°C) |
Treatment |
||
| Density (×1000 kg/m3) | 7.7-8.03 |
25 |
|
|
Poisson's Ratio |
0.27-0.30 |
25 |
|
|
Elastic Modulus (GPa) |
190-210 |
25 |
|
|
Tensile Strength (Mpa) |
667.4 |
25 |
annealed at 815℃ |
|
Yield Strength (Mpa) |
412.3 | ||
| Elongation (%) |
23.0 |
||
|
Reduction in Area (%) |
48.4 |
||
|
Hardness (HB) |
197 | 25 | annealed at 815℃ |
| Impact Strength (J) | 27.4 | 25 |
annealed at 815℃ |
Forging of Material AISI 6150 Steel
6150 alloy steel plate possesses several notable performance characteristics:
High Strength: It has a relatively high tensile strength and yield strength, enabling it to withstand significant loads and stresses without easily deforming or failing. This makes it suitable for applications where structural integrity and load-bearing capacity are crucial, such as in the construction of heavy machinery, automotive components, and aerospace structures7.
Good Toughness: Along with strength, 6150 alloy steel plate also exhibits good toughness. It can absorb impact and shock energy without cracking or breaking readily, providing reliable performance even in demanding operating conditions that involve dynamic loads or sudden impacts7.
Excellent Heat Treatability: This alloy steel can be subjected to various heat treatment processes to achieve different desired properties. For example, through proper heat treatment like quenching and tempering, its strength, hardness, and wear resistance can be enhanced. The ability to fine-tune its properties through heat treatment makes it adaptable to a wide range of specific application requirements7.
Moderate Hardness: It has a suitable level of hardness that provides a balance between wear resistance and ductility. This allows for good machinability while still maintaining the necessary durability for many applications.
Resistance to Fatigue: 6150 alloy steel plate shows good resistance to fatigue, meaning it can withstand repeated cyclic loading without prematurely failing. This is important for components that are subjected to continuous or intermittent stress over a long period, such as springs and some mechanical parts.
In summary, the combination of these performance features makes 6150 alloy steel plate a valuable material for a variety of industries and applications where high strength, toughness, heat treatability, and other mechanical properties are required.
