Description
Products Description
Standard Data Report for Grade A Shipbuilding Steel Plate / Q550CDE Steel Plate / Structural Steel Plate
Grade A Shipbuilding Steel Plate
Property Specification Data
Chemical Composition (% by weight) Carbon (C) Max 0.21
Manganese (Mn) 0.80 - 1.20
Silicon (Si) 0.15 - 0.35
Sulfur (S) Max 0.035
Phosphorus (P) Max 0.035
Mechanical Properties Yield Strength (MPa) Min 235
Tensile Strength (MPa) 400 - 520
Elongation (%) Min 22
Thickness (mm) Tolerance ±0.30 for thickness < 10mm, ±0.35 for 10 - 20mm
Q550CDE Steel Plate
Property Specification Data
Chemical Composition (% by weight) Carbon (C) Max 0.20
Manganese (Mn) 1.00 - 1.60
Silicon (Si) Max 0.55
Sulfur (S) Max 0.025
Phosphorus (P) Max 0.025
Chromium (Cr) 0.30 - 0.60
Nickel (Ni) 0.50 - 1.50
Molybdenum (Mo) 0.10 - 0.30
Vanadium (V) 0.02 - 0.20
Mechanical Properties Yield Strength (MPa) Min 550
Tensile Strength (MPa) 670 - 830
Elongation (%) Min 16
Thickness (mm) Tolerance ±0.25 for thickness < 15mm, ±0.30 for 15 - 30mm
| Product Name | Carbon Steel Plate |
| Material | Carbon Steel |
| Standard | CCS, DNV, GL, ABS, LR, BV, etc |
| Grade | Grade A/B/D/E/ AH32/AH36/DH32/DH36/EH32/EH36Q345CDE/Q390CDE/Q420CDE/Q460CDE Q550CDE/Q690CDE Q345CDE-Z15/Z25/Z35 |
| Thickness | 6mm-650mm or Customized |
| Length | 3000mm-18800mm or Customized |
| Width | 1500mm-4020mm or Customized |
| Package | Standard export seaworthy package or as required. |
| Processing Service | Bending, Welding, Decoiling, Punching, Cutting |
| Tolerance | ±1% |
| Delivery Time | within 7 Days |
| Place of Origin | shanghai, China |
| Package | Standard export seaworthy package or as required. |
| Transport Package | Customer's requirement |
| MOQ | 1Ton |
Structural Steel Plate
Property Specification Data
Chemical Composition (% by weight) Carbon (C) Varies depending on grade
Manganese (Mn) Varies depending on grade
Silicon (Si) Varies depending on grade
Sulfur (S) Max 0.050
Phosphorus (P) Max 0.045
Mechanical Properties Yield Strength (MPa) Varies depending on grade
Tensile Strength (MPa) Varies depending on grade
Elongation (%) Varies depending on grade
Thickness (mm) Tolerance ±0.20 for thickness < 8mm, ±0.25 for 8 - 16mm
Why Choose Us?
We take pride in our ability to provide custom solutions for our customers' unique needs.
We analyze and compare the previous products and the current technical situation of our Grade A Shipbuilding Steel Plate / Q550CDE Steel Plate / Structural Steel Plate, and develop new technical specifications and processes.
Our customers trust us to deliver high-quality Cold-rolled Steel products on time and on budget.
We strictly implement the warm and thoughtful after-sales service, adhere to the development of good professional ethics.
We offer a wide range of Cold-rolled Steel products to meet diverse customer needs.
We adhere to the customer-centric and brand-oriented business philosophy, and continue to provide customers with reliable and excellent products and services.
Our factory is committed to upholding the highest standards of safety and quality.
All staff of our company and all departments work together to combine business management, professional technology, quantitative statistical methods and ideological education.
Our Cold-rolled Steel products are known for their durability and reliability.
Relying on the superior conditions and strong advantages of mass production, we are able to meet the different needs of our customers.
