Density



The density of DNV LR ABS EH36 ship steel plate is similar to that of ordinary steel, approximately 7.85g/cm³. This density value is of great importance for calculating parameters such as the weight and center of gravity of the ship hull in ship design. For example, when designing a large - scale ship, the accurate density of the steel can assist engineers in precisely estimating the weight of the steel part of the ship hull, thus enabling a reasonable configuration of parameters related to the buoyancy and stability of the ship.



Thermal Properties



Coefficient of Thermal Expansion: The EH36 ship steel plate has a certain coefficient of thermal expansion. It will expand or contract correspondingly with the change of temperature. Its coefficient of thermal expansion is approximately 12×10⁻⁶/°C (in the range near normal temperature). This means that when a ship sails from a cold sea area to a warm sea area, the steel plate will expand due to the temperature rise. If this factor is not considered during the ship structure design and construction process, it may lead to structural deformation, weld cracking and other problems.













Shipbuilding Steel Plate Specification
Standard	CCS,ABS,GL,BV,DNV,NK,LR,KR,RINA
Grade	A/B/D/E,A32/D32/E32/F32,A36/D36/E36/F36, A40/D40/E40/F40,A131A/B/D/E/AH32/DH32 /EH32/AH36/DH36/EH36/AH40/DH40/EH40 ,NVA420/D420/E420,NVA460/D460/E460 ,NVA500/D500/E500,NVA550/D550/E550….
Thickness	2-300mm (2-100mm usually used)
Width	1000-3000mm (1000-2200mm usually used)
Length	1000-12000mm or as your request





Thermal Conductivity: The thermal conductivity of this steel plate has a certain impact on the heat insulation and fire - proofing of the ship. It has a certain ability to conduct heat and can transfer heat inside the steel. The thermal conductivity is approximately 40 - 50W/(m・K) (the specific value may vary slightly due to factors such as the microstructure and impurities of the steel). In the heat - insulation design of a ship, understanding the thermal conductivity of the EH36 steel plate can help in the selection of appropriate heat - insulation materials to reduce heat transfer. For example, this factor needs to be considered in the design of the bulkhead around the engine room and other heat - generating areas of a ship.







Acoustic Properties



In terms of acoustics, the characteristics of the EH36 steel plate are also quite important. It has a certain sound velocity and acoustic impedance during the propagation of sound waves. The sound velocity in the steel is relatively high, approximately 3000 - 6000m/s (the specific value varies due to factors such as the internal structure of the steel). In ship design, especially for areas where sound - insulation and noise - reduction need to be considered (such as the crew's living quarters), understanding the acoustic properties of the steel plate can help in adopting appropriate sound - insulation measures, such as adding sound - absorbing materials to reduce noise transmission. At the same time, when using acoustic equipment for ship inspection (such as ultrasonic flaw detection), the acoustic property parameters such as sound velocity and acoustic impedance of the steel are the key factors for accurate detection.









Why Choose Us?
We take pride in our ability to provide custom solutions for our customers' unique needs.
We analyze and compare the previous products and the current technical situation of our Lr ABS Dh36 Shipbuilding Steel Plate, and develop new technical specifications and processes.
Our customers trust us to deliver high-quality Cold-rolled Steel products on time and on budget.
We strictly implement the warm and thoughtful after-sales service, adhere to the development of good professional ethics.
We offer a wide range of Cold-rolled Steel products to meet diverse customer needs.
We adhere to the customer-centric and brand-oriented business philosophy, and continue to provide customers with reliable and excellent products and services.
Our factory is committed to upholding the highest standards of safety and quality.
All staff of our company and all departments work together to combine business management, professional technology, quantitative statistical methods and ideological education.
Our Cold-rolled Steel products are known for their durability and reliability.
Relying on the superior conditions and strong advantages of mass production, we are able to meet the different needs of our customers.
