Marine Steel Plate Hot Rolled Shipbuilding Steel VL EH36





"Physical Properties of Marine Steel Plate Hot Rolled Shipbuilding Steel VL EH36: A Case Study"



In the world of shipbuilding, the selection of high-quality steel is crucial for ensuring the safety, durability, and performance of vessels. One such steel that has gained prominence in the industry is Marine Steel Plate Hot Rolled Shipbuilding Steel VL EH36. This steel offers a unique combination of physical properties that make it an ideal choice for various shipbuilding applications.



The physical properties of VL EH36 steel play a vital role in determining its suitability for shipbuilding. Let's take a closer look at some of these properties through a case study.



Strength and Toughness



One of the most important physical properties of VL EH36 steel is its high strength and toughness. This steel has a yield strength of at least 355 megapascals (MPa) and a tensile strength ranging from 490 to 630 MPa. These impressive strength values enable the steel to withstand the heavy loads and stresses that ships experience during their operational life.



The toughness of VL EH36 steel is also remarkable. It can absorb energy without fracturing, making it highly resistant to impacts and sudden loads. This property is essential for ships that may encounter rough seas, collisions, or other unforeseen events. The combination of high strength and toughness provides a reliable and durable material for the construction of ship hulls, decks, and other structural components.



Steel Grade	C	Si	Mn	P	S	Als
A	≤0.21	≤0.50	≥2.5c	≤0.035	≤0.035
B	≤0.21	≤0.35	0.8~1.2	≤0.035	≤0.035
D	≤0.21	≤0.35	0.6~1.2	≤0.035	≤0.035	≥0.015
E	≤0.18	≤0.35	0.7~1.2	≤0.035	≤0.035	≥0.015
AH36	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
DH36	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
EH36	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
FH36	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015



Specification we supply：

Thickness	2-200mm
Width	1000-4000mm
Length	5000-15000mm



Case Study: Application of VL EH36 Steel in a Large Cargo Ship



To illustrate the practical application of VL EH36 steel's physical properties, let's consider a case study of a large cargo ship. The ship's hull is constructed using VL EH36 steel plates, which are selected for their high strength, toughness, weldability, corrosion resistance, and formability.



During the construction process, the steel plates are welded together using advanced welding techniques to form a strong and watertight hull. The high strength of VL EH36 steel ensures that the hull can withstand the heavy loads and stresses of the cargo and the marine environment. The toughness of the steel provides added safety in case of collisions or other impacts.



The corrosion resistance of VL EH36 steel is enhanced by applying protective coatings and implementing cathodic protection systems. This helps to prolong the service life of the ship and reduce maintenance costs over its operational life.



The formability of VL EH36 steel allows for the creation of complex shapes and structures in the ship's hull, such as curved sections and reinforced areas. This enables the ship to be designed for optimal performance and efficiency.
