30CrMnSiA steel round bar is a high-performance alloy structural steel product, highly regarded in industries demanding superior strength, toughness, and reliability. Below is a more detailed breakdown of its characteristics, specifications, heat treatment, and applications:

Key Chemical Composition (Typical, % by Weight)

The alloying elements in 30CrMnSiA contribute to its exceptional properties:



Carbon (C): 0.27-0.34% – Enhances hardness and strength.

Chromium (Cr): 0.80-1.10% – Improves hardenability and corrosion resistance.

Manganese (Mn): 0.80-1.10% – Boosts tensile strength and hardenability.

Silicon (Si): 1.10-1.40% – Enhances oxidation resistance and strength.

Aluminum (Al): ≤0.08% – Aids in deoxidation during production.

















Mechanical Properties (After Quenching and Tempering)

Tensile Strength: ≥1080 MPa – Indicates the material's ability to resist breaking under tension.

Yield Strength: ≥835 MPa – Reflects the stress at which the material begins to deform permanently.

Elongation: ≥10% – Measures the material's ability to stretch before fracturing.

Reduction of Area: ≥45% – Shows the degree of necking (localized reduction in cross-section) before failure.

Impact Toughness: ≥39 J (at room temperature) – Demonstrates resistance to sudden impact loads.

Heat Treatment Requirements

Quenching: Typically heated to 880-900°C, followed by rapid cooling in oil. This process hardens the steel by forming martensite, a hard and brittle microstructure.

Tempering: After quenching, the steel is heated to 540-600°C and held, then cooled in air. Tempering relieves internal stresses, reduces brittleness, and balances strength with toughness.











Why Choose Us?
We take pride in our ability to provide custom solutions for our customers' unique needs.
We analyze and compare the previous products and the current technical situation of our 30CrMnSIA Steel Round Bar, and develop new technical specifications and processes.
Our customers trust us to deliver high-quality Cold-rolled Steel products on time and on budget.
We strictly implement the warm and thoughtful after-sales service, adhere to the development of good professional ethics.
We offer a wide range of Cold-rolled Steel products to meet diverse customer needs.
We adhere to the customer-centric and brand-oriented business philosophy, and continue to provide customers with reliable and excellent products and services.
Our factory is committed to upholding the highest standards of safety and quality.
All staff of our company and all departments work together to combine business management, professional technology, quantitative statistical methods and ideological education.
Our Cold-rolled Steel products are known for their durability and reliability.
Relying on the superior conditions and strong advantages of mass production, we are able to meet the different needs of our customers.
